Triple Seven Pawn Evo

Safe and relaxed from school to cloud base. The new Pawn Evo is developed for maximum safety and flying ease. As such, this glider is ideal for beginner pilots just starting the game of paragliding adventures. With the long count of the latest technologies incorporated in this new wing, the Pawn Evo stands for a wing, that the student will use for a more extended period. The performance matching the latest low B wings will make these pilots crunch their first XC kilometers with ease and safety of the A-class.

Main Features

• BPI Back position intake technology for spin and stall resistance and good stability at high speeds
• VDO Visual design optimization
• STE smooth trailing edge
• Easy launch and landing characteristics
• Progressive handling and easy control characteristics
• Well balanced wing for maximum ease of piloting
• Robust and durable design and materials
• EN-A, LTF-A class
• Paramotor certification class 1

Materials

Back Position (air) Intake

On conventional paragliders, the location of the cell openings is always a compromise. The cell openings on paragliders must be located at the separation point (the place where the airflow separates into a part that travels OVER the wing, and another part that travels UNDER the wing) and because there is just one separation point, the cell openings must be either very large, or placed either at the separation point for trim speed, top speed or somewhere in between.

At Triple Seven, ALL their wings have been incorporating dual separation point aerofoils since the very first model – they call it the Back Position Intake. On Triple Seven wings the cell opening is located right between the two separation points, allowing Triple Seven to make it smaller while maintaining maximum inflow and thus maximum internal pressure at all angles of attack. With smaller cell openings and greater internal pressure, the collapse tendency at all speeds is significantly reduced, and the brake authority is increased – a big brake input from behind momentarily increases the pressure at the leading edge because the air cannot escape through the small openings, and this makes the leading edge more solid, less collapse-prone for the experienced pilot.

But due to the nature of the BPI even inexperienced pilots benefit from the BPI technology – the stall characteristics are significantly better, and the wing collapses much less in the first place. Triple Seven has also found that BPI aerofoils have better energy retention, making them more efficient in turbulent air – they aren’t as susceptible to being stopped in their tracks by sudden surges, something that makes them convert bumps along the way into altitude much better than conventionally designed paragliders.

Triple Seven was the first manufacturer to employ BPI technology to the full model range, and their extensive experience with this game-changing technology is just one more reason why they believe that a Valic-designed wing will make your flying more rewarding every time you take your wing out of its bag. At the end of the day, this is precisely what paragliding is about  – getting the most out of every flying opportunity, regardless of your own personal goals!

Visual design optimisation

There’s more to the design than meets the eye. Each and every seam has been placed precisely where it is for a reason, and there are no more seams in the canopy than necessary for the optimal panel tensioning everywhere. The reason Triple Seven mention this is if you design for looks rather than for efficiency you often end up with many more seams than you should ideally have, and every single one will increase the total air permeability of the canopy. In extreme cases this may lead to porosity issues at readings that wouldn’t normally be considered critical – if too much air is escaping via the many seams, then smaller increases in porosity in the individual panels may cause the whole wing to fall over the edge of what is still flyable.

When flying a Triple Seven wing you can rest assured that none of the design elements have been incorporated out of vanity – there are only technical solutions. Fortunately, the discerning pilot will instinctively associate efficient with attractive!

Smooth Trailing Edge

The paraglider’s trailing edge is a critical part of the design for both glider handling and performance, and one where Triple Seven invest a lot of effort into perfecting it. As the paraglider is inflated, the pressure inside makes the cells billow, and the Triple Seven STE technology is there to control the billowing near the trailing edge. Too much billow in this region shortens the trailing edge in a spanwise direction and may make the canopy pitch unstable in combination with pressure changes. Besides, too much billow at this critical part of the canopy adversely affects performance, because it may cause the airflow to separate in an uncontrolled manner.

With the Triple Seven STE technology, the designers have managed to completely eliminate excessive billowing, making for a much more coherent and sharp trailing edge. This is great news for performance and handling because the solid trailing edge transmits brake line input into turns much more readily.
